X-FLO™ Detector Sensors/Pads

X-FLO detector pads have been developed in direct response to the Traffic Management Industry's demand for reliable in-ground detection for pedestrians and bicycles.





X-FLO Pressure Pads    PATENT 332378

Features

  • Based on induction loop technology.
  • X-FLO™ connects directly to all standard loop-detectors and  traffic controllers.
  • Compatible with most traffic signal equipment  via loop detectors.
  • Innovative design allows simple, one person installation.
  • Constructed from robust laser-cut stainless steel.
  • Tested in accordance with UKHA Type Approval TR2182b.
  • Multiple units can be connected in series or parallel.
  • Available in Tactile or Flat formats.
  • Tactiles conform to international standards.
  • Snowplowable installation possible in bikepaths and sidewalks.
      Option: Pad can be cast with standard or custom colors, symbols and or words.

Functions

  • Detects pedestrians, bicycles, roller-blades, horses, snowmobiles etc.
  • Cancels Ped Calls - if pedestrian leaves detection zone prior to
    "Cross" phase.
  • Makes Ped Calls - as an alternative to a "Call-Button".
  • Greatly improves traffic flow and pedestrian safety.
  • Improves Driver and Pedestrian behavior at crosswalks and PUFFIN crossings.
  • Passive activation of in-pavement lights or LED markers.
  • Assess the volume of pedestrians waiting at a pedestrian crossing.
  • The X-FLO Pedestrian/Bicycle Detector can be used in conjunction with a push-button

Animation: Play the video now

Click on the image to the right to view an animation highlighting features and functionality of X-FLO.

It is recommended to save the animation to your hard drive first, then play it using a media player.

Here in the US the most common usage is as an independent in pavement signal call and cancel sensor.
play X-FLO animation (WMV format, 16.4 MB)

Specifications

Physical Dimensions: 600mm x 900mm x 100mm (23.7" x 35.5" x 3.9")
Total Weight: 32kg (70.5 lbs)
Inductance: 85 microhenries.
Min Detect: 15kg (33 lbs)
Operating Temp: -40c > +80c.
Humidity: 0% > 95%.
Load Test: 7500kg+ (16,500+ lbs)
EPDM Matting QUV: de:0.74.
EPDM Matting Skid Resistance:
Dry Wet
0° 180° 0° 180°
90 95 40 40

X-FLO™ units are made from 100% recyclable materials.
